10/8E-M 10x8E-M Pump Head, Bare Shaft Pumps Description

10x8E-M Medium Duty Slurry Pump

SPECIFICATIONS:

Size: 10" to 8"

Capacity: 666-1440 m3/h

Head: 14-60 m

Speed: 600-1100rpm

NPSHr: 4-10m

Eff.: 73%

Power: Max.120kw

Handling solids: 65mm

Materials: Hyper chrome alloy, Rubber, Polyurethane, Ceramic, Stainless steel etc.

10x8E-M Medium Duty Slurry Pump is cantilevered, horizontal and centrifugal with double casing structure, It is mainly suitable for pumping medium concentration slurries, 10x8E-M slurry pump applies in coal washer processing, handling with the fine ore and tailings in metal mine, handing combined bottom and fly ash in a thermal power station etc.

Design Features:

√ Modular design for ease of maintenance.

√ Medium duty one-piece frame base with lifting points for easy maintenance.

√ Standard ductile iron outer casings for higher working pressures and incorporating lifting points.

√ Standard or advanced bearing assembly improves reliability to extend bearing life reduce lubrication costs.

√ Shaft sealing for increased reliability, stuffing box, expeller, elevated seal or mechanical seal options available.

√ Standard or advanced impeller design options available.

√ Allows ease of fitting multiple liner materials, including hard metal, thick section rubber or polyurethane.

√ Single piece sleeve for stuffing box sealing, lowers stock holding and maintenance.

√ Multi-purpose design allows for reduced inventory requirements and interchangeability.

√ Belt guards allows for ease of maintenance and inspection of belt condition.
