Tobee Impeller C2147A05A for 3x2C-AH Slurry Pump
- Model Number: 3x2C-AH
- Brand Name: Tobee
- Place of Origin: Hebei, China
- Minimum Order Quantity: 1
- Supply Capacity: 2000/month
- Payment: T/T
- MemberShip: Free Member
- Inquiry Now
3x2C-AH Tobee Impeller C2147A05A for 3x2C-AH Slurry Pump Description
Sales7(at)tobeepump.com
Tobee® Slurry Pump impeller C2147A05A is one of the most important parts of 3x2C-AH Centrifugal Slurry Pump. It is closed type with 5 vanes. It is easy to be worn out, so we search for the special materials to prolong the lifespan of impeller, high chrome alloy is one of them, aims at handling the slurries with strong abrasion or sharp particles.
Here are three different types of slurry pump impellers: open, closed, and semi-open. Each has its own strengths and weaknesses, depending on the application. Some are better for solids handling, others are better for high efficiency. To learn more about the specifics of each type of impeller.
Any type of impeller can be used in slurry applications, but closed slurry pump impellers are more common because they are high efficient and abrasion Resistance,. Open slurry pump impellers are usually used well for high concentration solids as they are less likely to clog. For example, the small fibers in paper stock which, in high densities, may have a tendency to clog the impeller. Pumping slurry can be difficult and you want to avoid a clogged pump at all costs.
Slurry pumps contain several wetted parts that are essential for operation, including the volute liner, throat bush, frame plate liner insert, and the impeller. The pump impeller is one of the most important parts of the slurry pump. It is located in the pump body on the shaft and connects with the motor to form a centrifugal force system. When the motor drives the impeller to rotate, the blades force fluid to rotate, increasing its pressure, potential energy, and kinetic energy. At the same time, under the force of inertia, fluid flows from the center to the edge of the impeller, out at a very high speed, and passes through the discharge pipeline to be transported. When an impeller is rotating, and in good condition, the slurry pump can easily meet output expectations. They are, however, highly prone to wear and require regular maintenance to ensure efficiency.
Slurry Pump Spare Parts Applications:
Heavy Mining | Mineral Processing | Coal Prep | Cyclone Feeds | Aggregate Processing | Fine Primary Mill Grinding | Chemical Slurry Service | Tailings | Secondary Grinding | Industrial Processing | Pulp And Paper | Food Processing | Cracking Operations | Ash Handling | Pipeline Transport | High Velocity Hydraulic Transport |Food Processing | Explosive Sludge In Metal Smelting | River And Pond Dredging | Heavy Refuse Removal | Larger Particle Or Low NPSHA Applications | Continuous (Snore) Sump Pump Operation | Abrasive Slurries | High Density Slurries | Large Particle Slurries | Sump Drainage | Washdown | Floor Drainage | Mixing
