32CQ-15F CQ-F engineering plastic PP magnetic drive pump Description

CQ-F engineering plastic magnetic drive pump is made of reinforced polypropylene PP as the main material. The flow components of the pump are made of whole plastic injection molding. The pump is widely used to convey most of the organic and inorganic acid, alkali and salt solutions etc.  The pump is also suitable for outdoor exposure in the atmosphere and has the features of corrosion resistance and crack resistance.

Excellent corrosion resistance

Main components are made of highly corrosion resistant materials (reinforced polypropylene engineering plastic) with magnetic driving coupling to motor to ensure transfer the chemical liquids without any leakage.

The pump is made of whole plastic injection for the high efficiency and energy-saving. The structure is simple and convenient to use and disassemble.

Modelinlet(mm)outlet(mm)Head(m)flow(L/M)motor power(KW)Speed(rpm)Voltage(V)8CQ-2F862150.025280022010CQ-3F10103190.025280022014CQ-5F14105200.038280022014CQ-5F14105200.122800220/38016CQ-8F16128300.122800220/38020CQ-12F20141250O.372800220/38025CQ-12F25201280O.372800220/38025CQ-15F2520151101.12800220/38032CQ-15F3225151101.12800220/38032CQ-25F322525901.12800220/38040CQ-20F4032201801.5/2.2280038050CQ-25F5040252404280038050CQ-32F5040322204280038065CQ-32F6550324505.52800380

Flow rate	15-450L/M
Head	2-32m
Pump material	engineering plastic PP
